AEG TUMBLE DRYER DISPLAYS ERROR CODE EHE/EH0

AEG / ZANUSSI / ELECTROLUX DRYER DISPLAYS ERROR CODE EHE/EH0

Aeg droger code storing Eh0 EHo wasdroger Printplaat
Afbeeldingsresultaat voor zanussi droger

Error code EHE/EH0:

EH0 has to do with a defect in the circuit of the safety relay on the control panel. The processor registers and error in the voltage on the circuit board.

In other words, the PCB must be replaced and the costs are many hundreds of euros. But don’t worry. I can repair PCB for you.

What should you do

Double-check if the machine is realy out of order
Before you signup for repair, first double-check whether your machine realy has a defect. So no more lights or beeps when you switch the machine on – and check whether there is voltage on the outlet.

Signup for repair
If the machine still doesn’t work, then you can signup for repair.

How to dis-assemble the PCB

The PCB that we need is the print on the right side. Nr. 587 in the drawing.

Storing EH0 Eho aeg wasdroger

Remove the top from the machine by unscrewing 2 screws on the back of the top and 1 behind the condensation tray.

Unscrew the right side panel, these are the screws on the back.

Aeg wasdreoger EH0

You will now see the 2 screws that secure the circuit board to the machine.

Take the covers of the printed circuit board and disconnect all plugs.

IMG_5266
IMG_5265

You don’t have to loosen the print any further, just send the entire housing to us.

Printplaat reparatie protex wasdroger Storing EH0
Printplaat reparatie aeg zanussi electrolux wasdroger Storing EHO

This applies to all tumble dryers with the ON / OFF BUTTON under the program switch.

We repair – among others – to the following models:

Zanussi – Aeg  – Electrolux

EDC2086GDW
EDH97960W
T61270AC
T65370NAHT
75177NAV
T76385AH1
T86585IH
EDC2086PDW
EDI97170
Lavatherm 65170AV
T65470AH1
T75280AC
T76386NAH
T86589IH
EDC66150
EDP2074PEW
Lavatherm 65179AV
T67682NIH
T75370AH2
T76389NAH
T86595DIH
EDC67555W
EDR10621CA
T65270AC
T65771NIH
T75373NAH
T76485AH
T86597NIH
EDC77570
EDR10621
T65273AC
T71270AC
T75382NAH
T76485DIH
T87685DIH
EDE1074PDW
0194_0003 G
T65274AC
T71272AC
T5470IH1
T76485IH2
T87687NIH
EDH3386GDW
T65276AC
T71272NAC
T75480DIH
T76488IH2
T88595IS
EDH3686GDE
T65278AC
T71276AC
T75480IH1
T76782NIH
T88597NIS
EDH3786GDE
T35740
T65280AC
T72270AC
T76282AC
T76789NIH
T97689IH
EDH3786GDW
T37850
T65289NAC
T72276NAC
T76283AC
T77685DIH
EDH3886GDE
T5127AC
T65370AH3
T75175AV
T76285AC
T77687NIH
